─DATASHEET
Specifications
The hard data B2B buyers check first - compatibility, grade, and tested
tolerances at a glance.
|
Field |
Detail |
|
Compatible model |
Apple iPhone 6 (4.7") |
|
Model numbers |
A1549 · A1586 · A1589 |
|
Screen type |
IPS LCD (Retina HD) |
|
Available grades |
Original A+ / Incell / Standard (TFT) |
|
Resolution |
1334 × 750 px |
|
Touch controller IC |
Original-spec / high-stability compatible |
|
Color accuracy |
ΔE < [1.5] (Original grade) |
|
Inspection flow |
Power-on → display → touch → 48h aging → final QC |
|
Assembly |
LCD + touch digitizer + frame (full assembly) |
|
Color |
Black / White |
|
Packaging |
Anti-static bag + foam tray + reinforced carton + [optional per-unit test report] |
|
MOQ |
[e.g., from X units] |
|
Warranty |
[e.g., 12 months against manufacturing defects] |
Note vs newer models: the iPhone 6 uses IPS LCD (not OLED), has no 3D Touch and no Face ID. The Touch ID home button, front camera and sensor flex are transferred from the customer's original device - standard for iPhone 6 repairs. We list only what is true for this model.
─ENGINEERING / VERIFIABLE
Core Advantages
Not "good quality" - measurable process detail, because buyers judge a
screen supplier on yield and return rate.
01
Panel & Display Consistency
Each OEM iPhone 6 LCD Screen is built from graded IPS panels with controlled brightness and color output. We hold same-batch color deviation to ΔE < [1.5] on Original grade, so a 500-unit order looks uniform on the repair bench - no mix of warm and cold panels in one carton. Brightness is matched to [≥ X nits] for true-to-original readability.
02
Touch IC & Sensor Compatibility (the iPhone 6 weak point)
iPhone 6 screens fail most often at the touch controller IC - the cause of the well-known "grey flicker bar + dead touch" issue. We use high-stability touch ICs with reinforced flex bonding to keep touch response accurate and drift-free over time. The iPhone 6 Touch Screen Digitizer Replacement is calibrated for full-area multi-touch; the earpiece mesh ships installed, while the front camera, proximity/ambient-light sensor flex and Touch ID button are migrated from the original handset (Touch ID stays functional only with the device's original home button - true for all iPhone 6 assemblies, ours included).
03
Inspection & Quality Control Flow
Every unit follows a fixed, ordered test sequence - not a vague "strict QC" claim:
- Power-on test - boot and backlight check
- Display test - color, uniformity, dead-pixel, line-defect scan
- Touch test - full-area swipe + multi-touch response
- 48-hour aging test - runs continuously to screen out early-life failures
- Final QC before packing - fit, frame gap, connector, appearance
04
Packaging & Transit-Damage Protection
LCD breakage in transit is this industry's biggest hidden cost. Each iPhone 6 LCD Screen Replacement Wholesale unit is sealed in an anti-static bag, seated in a die-cut foam tray that isolates the glass from pressure, then packed into a reinforced master carton with corner protection - keeping our transit-breakage rate to [≤ X%]. Optional individually numbered units + per-unit test reports for traceability.
─CONVERSION / Choose the Right Tier
Grade Comparison
The biggest buyer concern is "which grade do I order, and will I get what I pay for?" Here is the honest, verifiable difference between our three tiers - no marketing fog.
|
|
Original A+ |
Incell |
Standard (TFT) |
|
Display & color |
Closest to genuine |
Accurate, full lamination |
Slightly cooler / more saturated |
|
Color accuracy (ΔE) |
< [1.5] |
< [3.0] |
[reference only] |
|
Brightness |
Highest |
High |
Moderate |
|
Touch feel |
Native-grade |
Smooth |
Good |
|
Durability |
Best |
Strong |
Standard |
|
Relative price |
$49.9 |
$29.9 |
$19.9 |
|
Best for |
Premium repair shops, high-end resellers |
Mainstream repair shops & distributors |
Price-sensitive bulk / emerging markets |
How to read this: if your downstream is premium customers who notice color and brightness, order Original A+. If you need the best balance of quality and margin for everyday repair-shop resale, Incell is the volume sweet spot. If you serve high-volume, price-first markets and want the slimmest landed cost per unit, Standard is built for that. Mixing grades in one order is fine - many of our distributors do exactly that to cover multiple price points.
most buyers compare here, then order a sample of two grades side by side.
─SUPPLY MODELS
Who This Is For
Phone repair shops & repair chains
Small-to-mid batches, fast dispatch, drop-in iPhone 6 Display Assembly with installation/troubleshooting support. Best fit: Original A+ or Incell.
Accessory wholesalers & distributors
Large recurring volume, tiered pricing, and consistent batch grading so your resale quality never drifts. Best fit: Incell + Standard mix for layered pricing.
Refurbishers & trade-in graders
Stable grade consistency batch-after-batch, with optional per-unit test reports for QA traceability. Best fit: Original A+ or Incell with reports.
─PROCUREMENT
Buyer FAQ
The real questions on a purchasing decision - answered up front
─FACTORY · DIRECT · NOMIDDLEMAN
Get your iPhone 6 LCD wholesale quote
Tier pricing, samples, and a written DOA policy - straight from the production line
